HDPE ( High density poly ethylene )
Today, high density poly ethylen is one of general plastics which are widely used in various industries. As our high density polyethylene sheets and rods are extruded with high molecular weight, they exhibit superior abrasion resistance and no toxic grade that enables them to use in food industry.
ㆍCharacteristics ㆍApplications
  • - Good machinable property
  • - Favorable abrasion resistance
  • - Favorable chemical resistance
  • - Workable even at low temperature
  • - Low water absorption rate
  • - Electrical mock-up parts
  • - Chemical container, Hopper, Lining parts
  • - Base material for bush, gear, roller

Standard Dimension
Sheet & Plates
Thickness
(mm)		 Thickness tolerance
(mm)		 Weight ( Kg/sheet )
W 1000mm x L 2000mm
10 +0.1 ~ +1.0 20.00
12 24.00
15 30.00
20 +0.1 ~ +2.0 40.00
25 50.00
30 60.00
35 +0.5 ~ +4.5 70.00
40 80.00
45 90.00
50 +0.5 ~ +4.5 100.00
60 120.00
70 +0.5 ~ +8.5 140.00
80 160.00
100 200.00
  • * Dimension and weight can be varied by tolerance in the specification.
  • * Customized size available upon request.
